SELECTION FOCUS
Questions that change the direction.
- Incoming edge condition
- Loading and release method
- Pocket population and orientation
Protected contact · Composite Lapping Carriers
Edge-Protection Composite Carriers
Composite pocket interfaces developed for thin, brittle or high-value substrates where edge contact is the primary risk.
HOW THIS PRODUCT IS JUDGED
Connect the physical product to its process function.
The design separates machine engagement from protected workpiece contact. Clearance is a review variable—not a universal value—and is confirmed from material, loading, liquid film and temperature.RFQ & DRAWING FIELDS
Evidence needed before release.
- Workpiece size and thickness distribution
- Protected faces and edge geometry
- Carrier flatness and pocket position
- Damage and yield acceptance
PRODUCT REFERENCE
Confirm the configuration for your part.
Top view with representative parts loaded, macro of one pocket edge and controlled-light flatness view.Do not submit confidential customer drawings until a secure project channel is confirmed.PUBLIC CLAIM BOUNDARY
Typical direction is not a performance guarantee.
Dimensions, materials, removal rate, roughness, life and compatibility are published only when supported by an approved drawing, material record or project-specific validation. Unverified label examples, third-party photographs and customer pricing remain internal references.
APPLICATION ROUTES
Where this product may enter the process.
ENGINEERING KNOWLEDGE
Read before selecting the specification.
RELATED TYPES IN COMPOSITE LAPPING CARRIERS
Compare neighbouring constructions.
Composite carrierMetal-Body Carriers with Polymer InsertsA rigid metal drive body with replaceable or integrated polymer contact zones around sensitive workpieces.NWS-CMC-2101NWS-CMC-2101 Metal and Epoxy Composite CarriersMetal and Epoxy Composite Carriers for wafers and precision optical parts. Double-sided lapping / polishing. Construction: Blue-steel or stainless-steel body with epoxy contact inserts; Thickness capability: From 0.25 mm; final thickness to drawing. Custom-made for the agreed process.
